Category: Vehicle unit
9 results

If you would like to request any modifications/additional development to the models in this service or FPGA implementation of your own physical models, we will consider it as an individual engineering project. For details, please contact Physical Model Hub support.

09/01/2023 612
This model is a brushed DC motor system, a physical model and a control model. The control model includes some calculators for a target current, a duty and a PWM signal. The physical model includes a battery, an H-bridge, and a equivalent c...
26/10/2022 714
Inline four cylinder naturally aspirated cyclic engine model that combines a cylinder, intake / exhaust pipe, crank, and starter.
26/10/2022 508
A four speed AT model that combines a torque converter, disc friction clutch, one-way clutch, Ravigneaux planetary gear.
29/10/2021 3406
Inline three cylinder naturally aspirated cyclic engine model that combines a cylinder, intake / exhaust pipe, crank, and starter.
29/10/2021 1075
A six speed AT model that combines a torque converter, disc friction clutch, one-way clutch, double pinion planetary gear and single pinion planetary gear.
29/10/2021 987
Simple electric motor model.
29/10/2021 1237
Simple three axis six degree of freedom vehicle model that combines differential gear, chassis, brakes, tires, and suspensions.
29/10/2021 1052
Simple electric motor model compatible with HDL Coder
29/10/2021 1831
This is an equivalent circuit battery model consisting of open circuit voltage, DC resistance, inductance, and two RC parallel circuits.
