Category: Vehicle system
10 results

If you would like to request any modifications/additional development to the models in this service or FPGA implementation of your own physical models, we will consider it as an individual engineering project. For details, please contact Physical Model Hub support.

23/01/2024 70
This model is an autonomous driving simulation model. By integrating vehicle control and vehicle physical models for BEV into a generic model (*1) of the autonomous driving simulation environment, it is possible to evaluate the cooperative...
22/01/2024 65
This model is a physical model for steering performance simulation of a CVT gasoline vehicle. It calculates the vehicle motion performance including the toe angle, caster angle, and tire behavior due to deformation and relaxation length. Th...
23/05/2023 281
This model is a physical model of CVT gasoline vehicle. It simulates transmission control and thermal performance. The powertrain consists of an engine (displacement 1.5 [L]), starter, alternator, transmission (CVT), differential, brakes,...
30/11/2022 361
This model is a prototype version of a physical model for simulation of vehicle motion performance assuming a CVT gasoline vehicle. The powertrain consists of an engine (displacement 1.5 [L]) and a CVT. The chassis consists of a steering wh...
30/11/2022 332
This model is a physical model for motion performance simulation of a CVT gasoline vehicle. The powertrain consists of an engine (displacement 1.5 [L]) and a CVT. The chassis consists of a steering wheel and a vehicle (4-wheel model with 3 ...
29/07/2022 783
This is an electric vehicle model for simulating electricity cost and thermal system. The powertrain of it consists of a motor (power rating: 110[kW]), a reducer mechanism, a vehicle, a low-voltage battery, and a high-voltage battery. And ...
25/05/2022 934
This is a prototype version of an electric vehicle model for simulating electricity cost and thermal system. It consists of a motor (power rating: 110 [kW]), a reduction mechanism, a vehicle, a low-voltage battery, and a high-voltage batte...
31/03/2022 749
This is a series hybrid electric vehicle model for simulating fuel and electricity cost. It consists of two motors, an engine (displacement: 1.2 [L]), a vehicle, a low-voltage battery, and a high-voltage battery. Control signals (throttle o...
28/02/2022 605
This is a hybrid electric vehicle model with a series parallel clutch mechanism for simulating fuel and electricity cost. It consists of two motors, an engine (displacement: 2.0 [L]), a clutch mechanism (transmission), a vehicle, a low-vo...
31/01/2022 675
This is a hybrid electric vehicle model with a series parallel power split mechanism for simulating fuel and electricity cost.
